Product Introduction:
High Transparency, High clarity, Low surface roughness, High Cleanness, High heat stability, Insoluble in Common solvents and petrol, Excellent Insulation performance, Excellent dimensional stability. Mainly used for window film for car and building( has functions of thermal insulation, energy conservation, anti-explosion, ultraviolet-proof, shielding privacy and safety protection).
Product Data Sheet:
NOMINAL THICKNESS | 23～125μm | METRIC UNITS | ||
Property | TEST METHOD | UNIT | TEST VALUE | |
AVERGE THICKNESS TOLERANCE | ASTM D374 | % | ±2 | |
TENSILE STRENGTH ≥ | MD | ASTM D882 | Mpa | 220 |
TD | 255 | |||
ELONGATION ≥ | MD | ASTM D882 | % | 125 |
TD | 110 | |||
MODULUS ≥ | MD | ASTM D882 | Mpa | 4300 |
TD | 4800 | |||
HEAT SHRINKAGE ≤ | MD | ASTM D 1204 150℃/30min | % | 1.4 |
TD | 0 | |||
Haze ≤ | ASTM D1003 | % | 1.6 | |
TRANSMITTANCE | ASTM D1003 | % | 99.4 | |
Clarity | % | 99.3 | ||
Gloss(45º) ≥ | ASTM D2457 | ﹣ | 135 | |
WETTING TENSION ≥ | ASTM D2578 | dyne/cm | 56 | |
Explain:
1.Wetting tension test is only applicable to corona treated film.
2.The results should, however, only be regarded as a general guide to material properties and not as a guarantee.
